Feature
*Compact structure,small foot print,higher store efficiency
*Plugin,Flexible placement,Convenient for promotion
*Whole body forming with better heat preservation,High compressive strength
*Brand controller,Accurate temperature control
*High efficiency EC fan motor,better energy saving
*Transparent slow recycling night blind
*Compact structure,small foot print,higher store efficiency
*Plugin,Flexible placement,Convenient for promotion
*Whole body forming with better heat preservation,High compressive strength
*Brand controller,Accurate temperature control
*High efficiency EC fan motor,better energy saving
*Transparent slow recycling night blind
*Electronic temperature control with display
*LED lighting horizontal (top of each shelf)
*Transparent slow recycling night blind
*4 layers solid shelves with LED light
| Model Number | DOS-980WX(VMC750-1930) | DOS-1310WX(VMC750-1930) |
| basic parameter | ||
| Climate | 3(25 ºC, 60%RH) | 3(25 ºC, 60%RH) |
| Total display area (TDA) | 1.83 Sqm | 2.25 Sqm |
| Net Capacity | 460L | 610L |
| Voltage / Frequency | AC 220-240V/50Hz | AC 220-240V/50Hz |
| Rated current | 4.85 A | 4.95 A |
| Rated power | 1060 W | 1100 W |
| Energy consumption | 15.8 kWh/24h | 18.5 kWh/24h |
| Temperature Range | 1~10ºC | 1~10ºC |
| Refrigerant,Qty | R404A | R404A |
| Side panel | Glass end panel | Glass end panel |
| Inner colours | White | White |
| Outer colours | Dark grey RAL7024 | Dark grey RAL7024 |
| Shelves layer | 4 layers solid shelves with LED light | 4 layers solid shelves with LED light |
| Supports | 4PCS(M18) | 4PCS(M18) |
| Night blind | Transparent slow recycling | Transparent slow recycling |
| Main Part | ||
| Compressor model | BOYARD QHD-16K | BOYARD QHD-16K |
| Evaporator | Copper tube aluminum fin | Copper tube aluminum fin |
| Evaporator motorfan | Saiwei 2*10W | Saiwei 2*10W |
| Condenser | Copper tube aluminum fin | Copper tube aluminum fin |
| Condensor motorfan | EBM 2*16W | EBM 2*16W |
| Drawing type condensing unit | N/A | N/A |
| Expansion valve | SPORLAN | SPORLAN |
| Thermostat | CAREL | CAREL |
| Light | T8 6500K 900mm 5*11W | T8 6500K 1200mm 5*16W |
| Drainage as standard | Water tank pouring,Manual | Water tank pouring,Manual |
| Inner tank bottom | Precoated steel sheet | Precoated steel sheet |
| Packing dimensions & Loading ability | ||
| Product (W*D*H) | 980*750*1930 | 1280*750*1930 |
| Packaging (W*D*H) | 1080*850*2120 | 1385*850*2120 |
| Net/Gross weight | 180/208 Kgs | 210/242 Kgs |
| Loading Qty (40HQ) | 26 | 21 |
1.Packaging and loading details:Standard exporting carton,professional loading to guarantee goods in good condition.
2. Loading time:45days after recieving 30%T\T and confirming the print materials.
2.We offer 1 years for the whole unit and 3 years for main part.
3. For the exporting products, 1% vulnerable spare parts will be supplied for free.
4.. OEM service is available.
5. We offer customers to visit the factory pick-up service.
6. We can help customers to book hotels.
1. Are you a trading company or factory?
We're factory. and also do trading.We export 38 countries across Europ, America, Africa and so on.2. How do I know your quality?
Detailed product photos and sample will be able to verify our quality.
3. Can I get a sample first?
Yes, sample is available.We can send out sample for test if the order quantity is big enough.
4. What's the MOQ?
Normally 1*40HQ,some models can be tried from small quantity. Pls check with our sales team to confirm.
5. Can i get Discount from buying your goods?
The price depends on the quantities, we'll automatically making discount to our customer.
6. How long your delivery?
According to your order,generally 45 workdays after confirming all the printing materials.
7. Can you make products from our designs?
Yes, we do OEM seivice
8. Shall we pay Extral cost for OEM service?
The OEM service are totally free of charge.
9. How do I make payment?
You could pay by Westunion, Paypal, T/T, L/C and other negotiable payment terms.
