| Model | LD3-2Z(C1) | LD3-2Z(C2) | LD3-2Z(C3) |
| Volume(m3) | 0.28 | 0.36 | 0.45 |
| Dimension(W*D*H)mm | 700x700x1980 | 900x900x1980 | 1200x840x1980 |
| Packing Dimension(mm) | 800x780x2180 | 1000x980x2180 | 1300x940x2180 |
| Voltage/frequency | 220V/50Hz | ||
| Refrigerant | R404a | ||
| Temperature range | 2-8ºC | ||
| Out/InnerMaterial | Prepainted Galvanized Steel | ||
| Compressor Brand | Embraco Aspera | ||
| Light | LED ligt strip 10W * 4/5 | ||
| Evaporator &condenser type | Fin type (copper tube + alluminum fin blade) | ||
| Evaporator Fan Power | 15W*4 | ||
| Condenser Fan Power | 15W*6 | ||
| Cooling Power | 3HP | ||
| Expansion Valve | Danfoss expansion valve | ||
| Auto-evaporation | wick type | ||
| Thermostat | Dixell digital control with LED display | ||
| Max.Ambinet Tempreture/Humidity | 25/65 | ||
| Shelves Number/load weight | 4/35KG | 5/35KG | 5/35KG |
| Gross /Net weight(KGS) | 160/180 | 205/240 | 280/320 |
| Loading Qty(20gp/40GP/40HQ) | 21/45/45 | 12/26/26 | 12/24/24 |
| Introduction and Feature: |
| 1, Auto-Defrost hot gas |
| 2, All Vertical LED lighting |
| 3, Famouse Apera brand compressor |
| 4, energy saving glass;with 4 heavy duty feets; |
| 5, digital tempreture control |
| Remarks and conditions: |
| 1) Price Term: FOB China, base on 220V/50Hz, 110V/60Hz Can be option,but have extral cost |
| 2) MOQ: 1x20'GP ,Maxmore two model mixed in one container.20GP charge $250/container FOB local cost |
| 3) Payment: 30% T/T before production and balance before loading; |
| 4) Delivery time: around 35 days after payment and artwork confirmation; |
| 5) Warranty: 3 years for compressor and 1 year for rest parts, 1% free spare parts against order qty. |
| 6) Quoation validity: 35 days after issue |
